Are All ATV Rims the Same Bolt Pattern? What You Must Know Before Buying

By admin1
26 June, 2025

Introduction
1. What Is a Bolt Pattern?
2. Common ATV Bolt Patterns Explained
3. How to Measure Your ATV’s Bolt Pattern
4. Are All ATV Rims Interchangeable?
5. Why Bolt Pattern Fitment Matters
6. Choosing the Right Rim from BRS Auto Parts
Conclusion
Contact Ningbo BRS Auto Parts

Introduction

If you’re shopping for new ATV wheels, one question often comes up: Are all ATV rims the same bolt pattern? While ATVs may look similar, the truth is far more complicated. Not all rims will fit all ATVs, and understanding bolt patterns is crucial to avoid buying incompatible parts.

In this guide, we’ll break down what bolt patterns are, how to measure them, which ones are most common, and how you can choose the right ATV rim—especially if you’re looking for a durable steel option from Ningbo BRS Auto Parts Co., Ltd..

1. What Is a Bolt Pattern?

The bolt pattern, also called the lug pattern, refers to the number of lug holes in a wheel and the diameter of the circle they form. It’s written as two numbers:

Lug count: the number of bolt holes (e.g., 4 or 5)
Pitch circle diameter (PCD): the diameter of the circle those lugs make (e.g., 110mm, 156mm)

Example: 4/110 means 4 lugs arranged in a 110mm diameter circle.

2. Common ATV Bolt Patterns Explained

There is no “one-size-fits-all” bolt pattern for ATVs. Below are the most commonly used configurations:

Brand	Common Bolt Pattern	Notes
Honda	4/110	Most models
Yamaha	4/110, 4/156	Depends on model/year
Polaris	4/156	Many sports and utility models
Kawasaki	4/137	Some UTVs
Can-Am	4/137	Large sport and UTVs

As you can see, even within the same brand, bolt patterns can vary significantly depending on the year and model.

3. How to Measure Your ATV’s Bolt Pattern

You can measure the bolt pattern manually if unsure:

Step 1: Count the number of lugs (usually 4 or 5).
Step 2: For 4-lug wheels, measure from the center of one hole directly across to the center of the opposite hole.
Step 3: For 5-lug wheels, measure from the center of one hole to the outer edge of the second hole (not directly opposite).

Use a caliper or metric ruler for best accuracy, since most bolt patterns are listed in millimeters. If you’re still unsure, check your owner’s manual or reach out to a professional supplier like BRS Auto Parts.

4. Are All ATV Rims Interchangeable?

No, ATV rims are not universally interchangeable. Just because the rim size matches (like 12×7) doesn’t mean the bolt pattern will. Bolt pattern, hub bore, offset, and load rating all affect compatibility.

Using the wrong bolt pattern can result in:

Wheel wobble and unsafe driving
Inability to mount the rim properly
Excess wear on wheel studs
Potential tire blowouts

5. Why Bolt Pattern Fitment Matters

Correct bolt pattern ensures:

Safe Fitment: Even load distribution and secure mounting
Proper Handling: Reduces vibrations and improves off-road stability
Longer Lifespan: Less wear on suspension and wheel components

Even slight differences in PCD (e.g. 4/110 vs 4/115) can prevent the rim from sitting flush against the hub. Using spacers or adapters is possible in some cases but not always ideal.

6. Choosing the Right Rim from BRS Auto Parts

At Ningbo BRS Auto Parts Co., Ltd., we understand how critical fitment is for performance, especially in rugged off-road environments. That’s why our ATV steel wheels are designed with exact bolt pattern specifications to match leading global brands.

📐 Precision Fit: All rims go through 2D/3D/CAE analysis for fitment accuracy
🔧 Custom Bolt Patterns: Available for 4/110, 4/156, 4/137 and more
🧪 Tested for Strength: In-house lab ensures compliance with real-world ATV stress conditions
🎯 OEM & Aftermarket: Compatible with Honda, Yamaha, Polaris, Can-Am, and others

With a 100,000 m² facility, BRS is China’s earliest steel wheel manufacturer and a strategic partner of Geely Group. Our wheels offer excellent durability, rust resistance (thanks to our shot-blasting and electrophoretic coating), and design flexibility.

Conclusion

So, are all ATV rims the same bolt pattern? Definitely not. Understanding your bolt pattern is crucial to choosing the correct wheel for your ATV. While rim diameter and width are important, bolt pattern is what ensures safe, secure installation.

Before buying any ATV rim, verify your pattern using a tape measure or check your vehicle specs. And if you’re seeking high-strength, precision-engineered rims, reach out to BRS Auto Parts—we build custom steel wheels that fit right the first time.
